Last updated on March 30th, 2024 at 11:00 am
Electronic devices and components have become a major part of our lifestyle, so their regular maintenance is necessary. Sometimes our devices have minor malfunctions that are easily repairable. You might be surprised to learn that many repairs can be performed at home. All you need is proper electronics repair tool kits and a little experience.
Running to the repair shop every time you have to do a minor repair can be quite inconvenient. You will save a lot of time, energy, and money if you do these repairs at home. Investing in the proper tools is the only cost you will bear. But people often tell us that they are unsure which tools to buy.
That’s why we decided to write this article, where we will guide you in selecting the necessary and proper electronics repair kits.
List of Electronics Repair Tool Kits
- Screwdriver set
- Multimeter
- Component Tester
- Components Kit
- Soldering Iron/ Soldering Station
- Electrostatic Mat
- DC Power Supply
- Wire Stripper
- Connecting Cables
- Alligator Clips
- Breadboard
- Microfiber Cloth
1. Screwdriver kit
Once an electronic device starts malfunctioning, the first thing we need to do is check the internal circuit. But the internal circuit is often protected by an outer casing. This casing is fitted to the device with the help of screws.
Now depending on the type and size of the device, each device has screws of different sizes. You cannot check the circuit without opening these screws. So to be adaptable for different sizes of screws, you will need a good screwdriver kit.
This Strebito Scredriver Set will be an excellent addition to your home repair kit. It has 120 different sizes and shapes of magnetic replaceable screwdrivers at just $27.99.
But if you think this is a bit much and you will never use these many options, then you can opt for VCELINK Screwdriver Set . At just $13, this tool kit gives you 45 size options.
2. Multimeter
Once you open the outer casing using a screwdriver set, you will gain access to the internal circuit of your device. The first step is to check whether all the components are functioning properly and operating within their rated voltage/current conditions. By doing so, you can pinpoint exactly which part of the circuit is causing the issue.
To perform these checks, you will need a multimeter. The two probes of a multimeter can be held at different points of the circuit to test for continuity. Additionally, you can measure the current drawn and voltage passing between any two points in the circuit.
We recommend buying the AstroAI Multimeter , as it provides the basic functions needed for your DIY repairs. And it costs only around $11.99. This is a very basic model that can measure current, voltage, and resistance.
3. Component tester
Some high-end multimeters also have a small built-in component tester. But we personally prefer having a separate component tester tool. We are currently using this Component tester from DROK and loving it. It can efficiently test triodes, field-effect tubes (FETs), diodes, resistors, capacitors, inductors, MOSs, and SCRs.
We really like its digital display and auto shutdown feature. Some may argue that having a component tester isn’t all that necessary. However, this is where they’re mistaken. You don’t want to discover that your newly repaired circuit is malfunctioning because you used a non-working component.
4. Components kit
Electronic components are the building blocks of an electronic circuit and device. All electronic devices have components like resistors, capacitors, transistors, inductors, diodes, etc. It’s wise to have spare components on hand in case one of them gets damaged. There are several component tool kits available in the market.
The above component kit is our absolute favorite. It has 5228 pieces of the most important and useful components.
5. Soldering iron/station
Now that you have all the means necessary to locate the problem, you need to start thinking about repairing it. You must remove and replace the faulty component with a new one. For this, you will need a soldering iron. You can refer to our article on Affordable Soldering Irons to get a top pick.
Anyone who has used a soldering iron knows that having just the iron is not enough. You will also need a solder mat, paste, tip cleaner, fume extractor, and many other accessories.
You don’t have to search for these items individually, as we’ve already compiled a list of kits that include everything you’ll need for soldering. You can check out our article on Best Soldering Stations for this.
If we need to pick the best of the best solution for soldering, then Yeegwin soldering station will be our first choice.
6. Electrostatic Mat
When you start repairing an electronic device, ensure you are in appropriate surroundings. You will be laying out many things, and there’s a huge possibility of things getting mixed up. It happens with components all the time.
If you leave new or used components lying around, they can build up a static charge. This static charge gets released in small bursts. You don’t want that burst to happen while placing a new component in your circuit because static electricity can damage other components.
The best way to deal with static charge is to drain each component before inserting it into your circuit. For this, you can use the ESD Anti-Static Table Mat . This mat comes with a wrist strap band with the metal underside and a removable alligator clip, an attachable grounding cord with a removable alligator clip, and a tabletop cleaner at just $39.98.
7. DC power supply
Having a reliable power supply is as important as a multimeter for testing. While repairing circuits and devices, you may need different voltages for your circuit. We recently tried the Kungber DC Power Supply , and our team is extremely happy with it. It has a high resolution of 0.01V and 0.01A. It can give an output of up to 10 A and 30 V.
This summarizes most of the items you will need in your electronics repair kit for home and DIY repairs. But there are still a few add-ons that will make your repair easier. Here’s a list of other tools that you might need in your repair kit:
- Wire Stripper: WGGE WG-015 Professional 8-inch Wire Stripper
- Connecting Cables: Bojack Precut Wires
- Alligator Clips: Romeda Alligator clips
- Breadboard: REXQualis Store Breadboard Kit
- Microfiber Cloth: MagicFiber Microfiber Cleaning Cloth
